45 Watt Single Output LED Power Supply

48 Volts @ 0.95 Amps

Specifications:

  • Universal AC input / Full range
  • Fully isolated plastic case with terminal block style of I/O
  • Built-in constant current limiting circuit
  • Adjustable output voltage and current level
  • Protections: Short circuit / Over load / Over voltage / Over temperature
  • Built-in active PFC function, comply with EN61000-3-2 class C( 75% load)
  • UL1310 class 2 power unit
  • Pass LPS
  • Cooling by free air convection
  • 100% full load burn-in test
  • High reliability
  • Suitable for LED lighting and moving sign applications
  • Compliance to worldwide safety regulations for lighting
  • 2 year warranty

    • Product Identification

    Product Type:Auto Switching SMPS
    Manufacturer Series:PLC-45

    Compliance

    Agency Approvals: CB, CCC, CE, EAC, EN, TUV, UL, UL, TUV, CB, CE, EN, EAC, CCC

    Dimensions & Appearance

    Style:Enclosed
    Color:White
    Height:1.38 in.
    Width:2.44 in.
    Length:7.15 in.

    Operating conditions

    Minimum Operating Temperature:-30°C
    Maximum Operating Temperature:50°C

    Input

    Input Frequency:47 Hz to 63 Hz
    Input Voltage:90 VAC to 264 VAC
    Maximum Input Current:0.55 A

    Output

    Number of Outputs:1
    Output Connector Type:Screw Terminal Block
    Output Voltage:48 VDC
    Output Current:0.95 A
    Output Range:43.6 VDC to 51.8 VDC

    Features

    PFC Function:Yes
    Minimum Isolation Voltage:3750V
    IP Rating:N/A
    Efficiency:87.5%
    Power Rating:45.6 W
    ,
