25W Single Output LED Power Supply

36 - 58 Volts @ 350 milliamps (mA)

Features:
  • Universal AC input / Full range (up to 295VAC)
  • Built-in active PFC function
  • Constant current design
  • Protections: Short circuit / Overload / Over temperature
  • Cooling by free air convection
  • Fully isolated plastic case
  • 100% full load burn-in test
  • High reliability
  • Suitable for dry / damp locations
  • Class II power unit, no FG
  • FCC and CE certified
  • 3 years warranty

Product Identification

Product Type:Auto Switching SMPS
Manufacturer Series:PLD-25

Compliance

Agency Approvals: CB, CE, EAC, EN, ENEC, FCC, UL, UL, CB, CE, FCC, EN, ENEC, EAC

Dimensions & Appearance

Style:Enclosed
Color:White
Height:1.16 in.
Width:2.24 in.
Length:3.30 in.

Operating conditions

Minimum Operating Temperature:-30°C
Maximum Operating Temperature:60°C

Input

Input Frequency:47 Hz to 63 Hz
Input Voltage:90 VAC to 295 VAC
Maximum Input Current:0.6 A

Output

Number of Outputs:1
Output Connector Type:Stripped and Tinned
Output Current:0.35 A
Output Voltage:See Output Range
Output Range:40 VDC to 58 VDC

Features

PFC Function:Yes
IP Rating:IP42
Minimum Isolation Voltage:3750V
Efficiency:85%
Power Rating:20.3 W
,
