16W Single Output AC Dimmable LED Power Supply

16 - 24 Volts @ 700 milliamps(mA)

Features:
  • AC Input Voltage: 90 - 135 VAC
  • AC phase-cut dimming
  • Work with leading edge and trailing edge TRIAC dimmers
  • Built-in active PFC function
  • Constant current design
  • Protections: Short circuit / Overload / Over temperature
  • Cooling by free air convection
  • Fully isolated plastic case
  • Class II power unit, no FG
  • FCC Certified
  • Suitable for indoor LED lighting applications
  • 100% full load burn-in test
  • Low cost
  • High reliability
  • 3 years warranty

Product Identification

Product Type:Auto Switching SMPS
Manufacturer Series:PCD-16

Compliance

Agency Approvals: EAC, EN, FCC, CUL, CUL, FCC, EN, EAC

Dimensions & Appearance

Style:Enclosed
Color:White
Height:1.16 in.
Width:2.24 in.
Length:3.30 in.

Operating conditions

Minimum Operating Temperature:-30°C
Maximum Operating Temperature:60°C

Input

Input Frequency:47 Hz to 63 Hz
Input Voltage:90 VAC to 135 VAC
Maximum Input Current:0.4 A

Output

Number of Outputs:1
Output Range:16 VDC to 24 VDC
Output Connector Type:Stripped and Tinned
Output Current:0.70 A
Output Voltage:See Output Range

Features

PFC Function:Yes
IP Rating:IP42
Minimum Isolation Voltage:3750V
Efficiency:81%
Power Rating:16.8 W
,
