650nm Line Laser Diode Module

Features

  • Class IIIB laser product
  • Focus adjustable with locking set screw
  • Laser line width: 1mm
  • Laser fan angle: 60°
  • APC power control
  • Current stable control
  • Wattage: 5mW
  • Operating voltage: 3-5V
  • Size: 3.3" length x 0.9" diameter
  • 1-year warranty
  • Power supply not included, (We recommend P/N: 1940660)
  • Note: Module mount not included, see P/N: 143853

Class 3B Laser Product Warning

Product Identification

Product Type:Laser Module - Line

Dimensions & Appearance

Color:Red
Dimensions:22.9mm Dia. x 83.8mm L

Input

Input Voltage:3VDC to 5VDC

Features

Beam Width:1 mm
Fan Angle (Deg.):60
Peak Wavelength:650 nm
Power Rating:5 mW
,
