Isolated DC-DC Converter 75W 5V 15A 180-450Vin Quarter Brick Negative Logic Remote ON/OFF
Product Identification
Type:Isolated
Manufacturer Series:CQB75-300S
Additional Feature:Negative Logic Remote ON/OFF
Product Type:Isolated DC-DC Converter Regulated Output SMPS
Compliance
Agency Approvals:UL, CUL, CB, CE, EN, UKCA
Dimensions & Appearance
Color:Black, Gray
Height:0.50 in.
Width:1.45 in.
Length:2.28 in.
Operating conditions
Maximum Operating Temperature:105°C
Minimum Operating Temperature:-40°C
Input
Input Voltage Range:180 VDC to 450 VDC
Maximum Input Current:0.52 A
Input Voltage:300 VDC
Output
Number of Outputs:1
Output Voltage:5 VDC
Output Connector Type:PC Pins
Additional Output Voltages (VDC):N/A
Output Current:15 A
Features
Isolation Voltage:3000VAC
Pins:8
AC Power Cord:N/A
Efficiency:83.5%
Power Rating:75 W
