Isolated DC-DC Converter 30W 24V 1250mA Regulated Output 150-1500Vin DIN Rail Type
Product Identification
Product Type:Isolated DC-DC Converter
Manufacturer Series:DH30W10
Compliance
Agency Approvals:UL1741, CSA, CE, EN, UKCA
Dimensions & Appearance
Color:Black
Height:1.71 in.
Width:2.76 in.
Length:5.31 in.
Mounting:DIN Rail
Operating conditions
Minimum Operating Temperature:-40°C
Maximum Operating Temperature:80°C
Input
Maximum Input Current:0.26 A
Input Voltage Range:150 VDC to 1500 VDC
Input Voltage:800 VDC
Output
Number of Outputs:1
Output Voltage (Channel 1):24 VDC
Output Current (Channel 1):1.25 A
Output Connector Type:Screw Terminals
Output Voltage:24 VDC
Additional Output Voltages (VDC):N/A
Output Current:1.25 A
Features
Pins:5
Minimum Isolation Voltage:4000VAC
AC Power Cord:N/A
Efficiency:89%
Power Rating:30 W
