Isolated DC-DC Converter 10W ±12V ±417mA Out 18-74Vin Negative Logic Remote On-Off PCB-Mount 1x1 No Tantalum Cap

Features

  • Efficiency up to 89.5%
  • Fixed Switching Frequency
  • Regulated Outputs
  • Negative Logic Remote On/Off
  • Low No Load Power Consumption
  • Fully Protected (OCP/OVP/UVLO)
  • 3000Vdc I/O Isolation
  • Operating Ambient Temperature -40 to +105°C
  • Meets Industrial Standard 1.0" x 1.0" x 0.40"
  • Safety Meets IEC/EN/UL 62368-1
  • EMI Meets EN 55032 Class A without External Component
  • No Tantalum Capacitor Inside

Overview

Isolated DC-DC Converter 10W ±12V ±417mA Out 18-74Vin Negative Logic Remote On-Off PCB-Mount 1x1 No Tantalum Cap.

Product Identification

Type:Isolated
Additional Feature:Negative Logic Remote ON/OFF
Product Type:DC-DC Converter SMPS
Manufacturer Series:EC2SBW-H

Compliance

Agency Approvals:CE, EN, UKCA

Dimensions & Appearance

Color:Black
Height:0.40 in.
Width:1 in.
Length:1 in.

Operating conditions

Maximum Operating Temperature:105°C
Minimum Operating Temperature:-40°C

Input

Input Voltage Range:18 VDC to 74 VDC
Maximum Input Current:0.236 A
Input Voltage:48 VDC

Output

Number of Outputs:2
Additional Output Voltages (VDC):-12 VDC
Output Voltage:12 VDC
Output Connector Type:PC Pins
Output Current:±0.417 A

Features

Pins:6
Isolation Voltage:3000V
Efficiency:89%
Power Rating:10 W
,
