IGBT Sic Gate Driver Power DC-DC Converter 2W 15V 110mA -3V -100mA SIP-7 15Vin

Features

• SIP7 package with international standard pinout
• Operating temperature range -40C to +90C
• Performance optimized for IGBT/SiC
• Bipolar asymmetric unregulated output
• Low coupling isolation capacitance (Cio)
• Protections: Short circuit (Continuous)
• 6.2KV DC pr 4.3KV AC high I/O isolation
• Low cost
• 3-year warranty

Overview

GD2 series is a 2W isolated and unregulated module type DC-DC converter with SIP7 package. It feature international standard pins, a high efficiency up to 82%, wide working temperature range of -40C to +90C, 6200VDC or 4300VAC I/P-O/P high isolation voltage, short circuit protection, and more. The models account for different input voltage 12V/15V/24V ±10%, and a variety of different output positive and negative voltages, which are suitable for ultra low leakage current, and applications like industrial control, telecommunication field, motor drivers and solar inverters, distributed power architecture, and so on.
