Decade Counter/Divider

Specifications

  • Counter and 7-segment decoding in one package
  • Easily interfaced with 7-segment display types
  • Ideal for low-power displays
  • 100% tested for quiescent current at 20V
  • Standardized, symmetrical output characteristics
  • Schmitt-triggered clock inputs

    Applications

    Decade counting 7-segment decimal display
  • Frequency division 7-segment decimal displays
  • Clocks, watches, timers
  • Counter/display driver for meter applications

    • Packaging

    Package:DIP-16
    ,
