5 Volt 64KX8 70 Nanoseconds EPROM

Specifications

  • 5V ± 10% SUPPLY VOLTAGE in READ OPERATION
  • ACCESS TIME: 45ns
  • LOW POWER "CMOS" CONSUMPTION: Active Current 30mA, Standby Current 100mA
  • PROGRAMMING VOLTAGE: 12.75V ± 0.25V
  • PROGRAMMING TIMES of AROUND 6sec.

    • Dimensions & Appearance

    Mounting:Through Hole

    Operating conditions

    Minimum Operating Temperature:0°C
    Maximum Operating Temperature:70°C

    Packaging

    Package:DIP-28

    Input

    Input Voltage:5V

    Output

    Output Enable Access Time:40ns

    Features

    Reprogramming Technique:UV
    Screening Level:Commercial
    Maximum Random Access Time:70ns
    Organization:64Kx8
    Memory Density:512Kbit
    ,
