Hall Effect Gear Tooth Speed Sensor

Designed for use in applications where ferrous edge detection/near zero speed sensing is needed. They provide a sinking current output.

Specifications

• Hall Effect Gear Tooth Speed Sensor with Adjustable Aluminum Housing
• Sense motion of ferrous gear tooth targets
• Near-zero speed sensing capability
• Immune from hostile environments
• Reverse battery protection from 24VDC
• Operating voltage range: 4.5-24VDC
• Supply current: 6mA max.
• Output voltage: 400mV max.
• Output current: 25mA max.
• Output: sink
• Wire: 20AWG x 1m
• Operating temp. range: -40°C to 125°C
• Housing: Aluminum, black
• Thread: 15/32" - 32
• Barrel length: 1.0"
