Film Capacitor Polyester Metallized 0.047uF 5% 50VDC Stacked Radial

Specifications

  • Series: ECQ-V
  • Capacitance: 0.047 µF (47 nF)
  • Tolerance: ±5%
  • Voltage Rating - DC: 50 V
  • Dielectric Material: Polyester, Metallized - Stacked
  • Operating Temperature: -40°C to 105°C
  • Mounting Type: Through Hole
  • Package: Radial
  • Size: 0.287" L x 0.126" W (7.30 mm x 3.20 mm)
  • Height - Seated (Max): 0.236" (6.00 mm)
  • Termination: PC Pins
  • Lead Spacing: 0.197" (5.00 mm)
  • Applications: General Purpose

Dimensions & Appearance

Mounting:Through Hole

Features

Capacitance (pF):47000
Tolerance:5%
Capacitance (uF):0.047
Capacitance:0.047 uF
Lead Pitch:9 mm
Voltage Rating:50 VDC
,
