Eurostrip12 Pole 15mm Spacing Flat Base 50A 300V 18-8AWG

Features

• Terminal Type: Screw, Wire Protector
• Series: HE Series
• Description: Eurostrip, 12 pole,15mm spacing, flatbase, 50A, 300V, 18-8AWG, Black
• Color: Black
• Panel Thickness: –
• Drill Hole Size: –
• Eurostrip: –
• Pole Spacing: –
• No. of Poles: –
• Dim & Weight (Pitch Spacing): 15 mm
• Weight Per Piece: 95.5 g
• Min Wire Size UL: 18 AWG
• Max Wire Size UL: 8 AWG
• Min Wire Size - SA: –
• Max Wire Size - SA: –
• Min Wire Size IEC: 6 mm²
• Max Wire Size IEC: 10 mm²
• Voltage Rating - UL: 300 V
• Voltage Rating - SA: –
• Voltage Rating - IEC: 400 V
• Current Rating -UL: 50 A
• Current Rating - SA: –
• Current Rating - IEC: 25 A
• Torque - UL / SA (ATS): 10.6 lb-in.
• Torque - IEC: 0.84 Nm
• Insulation Material: Polyamide 66/6 V0
• Insert Material: Tinned Brass
• Terminal Screw Material: Blue Chromated Steel
• Wire Stripping Length: 8.5 mm
• Mounting Hole Diameter: 4.5 mm
• Terminal Screw Size: M4
• Poles: 12
• Length: 174.2 mm
• Standard Pack: 10
• (Accessories) External Jumpers - 2pole: HCL15-2
• (Accessories) External Jumper - 3 Pole: HCL15-3
• (Accessoreis) External jumper - 4 Pole: HCL15-4
• (Accessories) External Jumper - 12 pole: HCL15-12
• Marking Plates -Blank: BS1016E
• Marking Plates No. 1-12: BS1016EM1-12
• Marking Plates No. 13-24: BS1016EM13-24
• Isolation Partition: –
• Mounting Pins: –

Overview

Eurostrip12 Pole 15mm Spacing Flat Base 50A 300V 18-8AWG
