Eurostrip Socket 8 Pole 10mm PS Flat Base 20A 300V 24-10AWG

Features

• Terminal Type: Plug & Socket
• Series: HE Series
• Description: Eurostrip socket, 8 pole,10mmPS, flat base, 20A, 300V, 24-10AWG, Black
• Color: Black
• Panel Thickness: –
• Drill Hole Size: –
• Eurostrip: –
• Pole Spacing: –
• No. of Poles: –
• Dim & Weight (Pitch Spacing): 10 mm
• Weight Per Piece: 30.4 g
• Min Wire Size UL: 24 AWG
• Max Wire Size UL: 10 AWG
• Min Wire Size - SA: –
• Max Wire Size - SA: –
• Min Wire Size IEC: 2.5 mm²
• Max Wire Size IEC: 4 mm²
• Voltage Rating - UL: 300 V
• Voltage Rating - SA: –
• Voltage Rating - IEC: 400 V
• Current Rating -UL: 20 A
• Current Rating - SA: –
• Current Rating - IEC: 10A
• Torque - UL / SA (ATS): 7.0 lb-in.
• Torque - IEC: 0.4 Nm
• Insulation Material: Polyamide 66/6 V0
• Insert Material: Tinned Brass
• Terminal Screw Material: Blue Chromated Steel
• Wire Stripping Length: 6 mm
• Mounting Hole Diameter: 3.6 mm
• Terminal Screw Size: M3
• Poles: 8
• Length: 76.4 mm
• Standard Pack: 50
• (Accessories) External Jumpers - 2pole: HCL10-2
• (Accessories) External Jumper - 3 Pole: HCL10-3
• (Accessoreis) External jumper - 4 Pole: HCL10-4
• (Accessories) External Jumper - 12 pole: HCL10-12
• Marking Plates -Blank: BS24E
• Marking Plates No. 1-12: BS24EM1-12
• Marking Plates No. 13-24: BS24EM13-24
• Isolation Partition: –
• Mounting Pins: –

Overview

Eurostrip Socket 8 Pole 10mm PS Flat Base 20A 300V 24-10AWG
