Eurostrip 3 Pole 8mm Spacing Flat Base 20A 300V 24-12AWG

Features

• Terminal Type: Screw, Wire Protector
• Series: HE Series
• Description: Eurostrip, 3 pole, 8mm spacing, flat base, 20A, 300V, 24-12AWG, Black
• Color: Black
• Panel Thickness: –
• Drill Hole Size: –
• Eurostrip: –
• Pole Spacing: –
• No. of Poles: –
• Dim & Weight (Pitch Spacing): 8 mm
• Weight Per Piece: 16.2 g
• Min Wire Size UL: 24 AWG
• Max Wire Size UL: 12 AWG
• Min Wire Size - SA: –
• Max Wire Size - SA: –
• Min Wire Size IEC: 1 mm²
• Max Wire Size IEC: 2.5 mm²
• Voltage Rating - UL: 300 V
• Voltage Rating - SA: –
• Voltage Rating - IEC: 400 V
• Current Rating -UL: 20 A
• Current Rating - SA: –
• Current Rating - IEC: 6A
• Torque - UL / SA (ATS): 4.4 lb-in
• Torque - IEC: 0.35 Nm
• Insulation Material: Polyamide 66/6 V0
• Insert Material: Tinned Brass
• Terminal Screw Material: Blue Chromated Steel
• Wire Stripping Length: 5.0 mm
• Mounting Hole Diameter: 3.0 mm
• Terminal Screw Size: M2.6
• Poles: 3
• Length: 21.2 mm
• Standard Pack: 100
• (Accessories) External Jumpers - 2pole: HCL8-2
• (Accessories) External Jumper - 3 Pole: HCL8-3
• (Accessoreis) External jumper - 4 Pole: HCL8-4
• (Accessories) External Jumper - 12 pole: HCL8-12
• Marking Plates -Blank: –
• Marking Plates No. 1-12: –
• Marking Plates No. 13-24: –
• Isolation Partition: –
• Mounting Pins: –

Overview

Eurostrip 3 Pole 8mm Spacing Flat Base 20A 300V 24-12AWG
