Eurostrip 12 Pole 12mm Spacing Standoff 40A 600V 20-10AWG

Features

• Terminal Type: Screw, Wire Protector
• Series: HE Series
• Description: Eurostrip, 12 pole,12mm spacing, standoff, 40A, 600V, 20-10AWG, Black
• Color: Black
• Panel Thickness: –
• Drill Hole Size: –
• Eurostrip: –
• Pole Spacing: –
• No. of Poles: –
• Dim & Weight (Pitch Spacing): 12 mm
• Weight Per Piece: 49.1 g
• Min Wire Size UL: 20 AWG
• Max Wire Size UL: 10 AWG
• Min Wire Size - SA: –
• Max Wire Size - SA: –
• Min Wire Size IEC: 4 mm²
• Max Wire Size IEC: 6 mm²
• Voltage Rating - UL: 600 V
• Voltage Rating - SA: –
• Voltage Rating - IEC: 500 V
• Current Rating -UL: 40 A
• Current Rating - SA: –
• Current Rating - IEC: 16A
• Torque - UL / SA (ATS): 7.0 lb-in.
• Torque - IEC: 0.55 Nm
• Insulation Material: Polyamide 66/6 V0
• Insert Material: Tinned Brass
• Terminal Screw Material: Blue Chromated Steel
• Wire Stripping Length: 5 mm
• Mounting Hole Diameter: 4.2 mm
• Terminal Screw Size: M3.5
• Poles: 12
• Length: 139.8 mm
• Standard Pack: 50
• (Accessories) External Jumpers - 2pole: HCL12-2
• (Accessories) External Jumper - 3 Pole: HCL12-3
• (Accessoreis) External jumper - 4 Pole: HCL12-4
• (Accessories) External Jumper - 12 pole: HCL12-12
• Marking Plates -Blank: BS60E
• Marking Plates No. 1-12: BS60EM1-12
• Marking Plates No. 13-24: BS60EM13-24
• Isolation Partition: HEP4/6H
• Mounting Pins: H6

Overview

Eurostrip 12 Pole 12mm Spacing Standoff 40A 600V 20-10AWG
