10W Encapsulated DC-to-DC Converter
Output: 5 Volts @ 2 AmpsFeatures:
- Input range: 9-18VDC
- Number of pins: 4
- Line Regulation: ±0.3%
- Load Regulation: ±1.0%
- Ripple and Noise: 50mVp-p
- Short-circuit/overload protection
- 1000VDC I/O isolation
- Shield metal case
- Cooling by free air convection
- Size: 2.0"L x 1.0"W x 0.44"H
Product Identification
Type:Step Down
Product Type:DC-DC Regulated Single Output Converter SMPS
Manufacturer Series:SKE10
Dimensions & Appearance
Height:0.44 in.
Width:1 in.
Length:2 in.
Operating conditions
Minimum Operating Temperature:-25°C
Maximum Operating Temperature:71°C
Input
Input Voltage Range:9 VDC to 18 VDC
Input Voltage:12 VDC
Output
Number of Outputs:1
Output Voltage:5 VDC
Additional Output Voltages (VDC):N/A
Output Current:2 A
Features
Pins:4
Power Rating:10 W
