Encapsulated AC-DC Power Supply 60W 12V 5A PCB Mount Class 2 Peak Load 2x Rated Current
Product Identification
Additional Feature:Class 2, Peak Load 2x Rated Current
Product Type:Power Module SMPS
Manufacturer Series:CFM61S
Compliance
Agency Approvals: CE, CUL, EN, FCC, Nemko, UKCA, UL
Dimensions & Appearance
Style:Encapsulated
Color:Black
Height:1.41 in.
Width:2.14 in.
Length:2.14 in.
Operating conditions
Minimum Operating Temperature:-30°C
Maximum Operating Temperature:80°C
Input
Input Frequency:50 Hz to 60 Hz
Input Voltage:90 VAC to 264 VAC
Maximum Input Current:1.5 A
Output
Number of Outputs:1
Output Voltage:12 VDC
Output Connector Type:PC Pins
Additional Output Voltages (VDC):N/A
Output Current:5 A
Features
PFC Function:No
Minimum Isolation Voltage:3000VAC
Efficiency:88%
Power Rating:60 W
