DIP Relay

Specifications:

  • Contact form: DPDT
  • Coil voltage: 12VDC
  • Coil resistance: 720Ω
  • Contact voltage: 110VAC/30VDC
  • Contact current: 0.3A/1A
  • Size: 0.79"L x 0.40"W x 0.43"H
  • 8-pin package
  • Fits Jameco socket 11222

Features:

  • Logic level controls
  • Long life with reliable operation
  • Excellent for PCB applications
  • Compatible with IC sockets
  • Compact design/construction
  • Moisture resistant

Compliance

RoHS Status:ROHS Compliant

Dimensions & Appearance

Height:0.43 in.
Width:0.4 in.
Length:0.79 in.

Features

Contact Current:0.3A/1A
Pins:8
Coil Voltage:12 VDC
Contact Voltage:110 VAC/30 VDC
Contact Form:DPDT
Coil Resistance:720 Ohm
,
