66W Dual Output AC/DC Enclosed Switching Power Supply

5 Volts @ 6 Amps (Channel 1)
12 Volts @ 3 Amps (Channel 2)

Specifications

  • Max. power rating: 66W
  • Efficiency: 79%
  • Size (L x W x H) (inches): 5.1 x 3.9 x 1.5
  • Ripple and Noise (mV p-p): 80
  • Load Regulation: 0.5%
  • Line Regulation: 0.5%
  • Input: 88-264VAC @ 47-63Hz
  • 5G Vibration
  • Able to withstand 300VAC surge input for 5 seconds
  • Short-circuit/overload/overvoltage protection
  • 3-year warranty
  • Certifications: UL/CUL/TUV/CE/CB

Product Identification

Type:Auto Switching SMPS
Product Type:AC to DC Power Supply
Manufacturer Series:RD-65

Compliance

Agency Approvals: CB, CE, CUL, EAC, EN, TUV, UL

Dimensions & Appearance

Style:Multiple Output
Color:Silver
Height:1.5 in.
Width:3.9 in.
Length:5.1 in.

Operating conditions

Minimum Operating Temperature:-25°C
Maximum Operating Temperature:70°C

Input

Input Frequency:47 Hz to 63 Hz
Input Voltage:88 VAC to 264 VAC
Maximum Input Current:2 A

Output

Number of Outputs:2
Output Voltage (Channel 2):12 VDC
Output Voltage (Channel 1):5 VDC
Output Current (Channel 2):3 A
Additional Output Voltages (VDC):12
Output Voltage:5 VDC
Output Connector Type:Screw Terminal Block
Output Current (Channel 1):6 A
Output Current:6 A

Features

Minimum Isolation Voltage:3000V
Efficiency:79%
Power Rating:66 W
,
