Dual Output 3W ±15V ±0.1A DIP-24 Isolated Regulated DC-DC Converter 48Vin

Output: +/-15 Volts @ +/-0.1 Amps

Features

  • DIP24 package with industry standard pinout
  • 2:1 wide input range
  • Input voltage range: 36V to 72V
  • Line regulation: ±0.5%
  • Load regulation: ±1%
  • Operating temperature range: -40°C to +90°C
  • No minimum load required
  • Complies with EN55032 radiated Class A without additional components
  • High efficiency up to: 87%
  • Protections: Short circuit (continuous), overload, input under voltage
  • 3KVDC I/O isolation
  • 3 year warranty

Applications

  • Telecom and Datacom systems
  • Wireless networks
  • Industrial control facilities
  • Instrument
  • Analyzer
  • Detector
  • Data switch

Product Identification

Type:Isolated
Manufacturer Series:DCWN03
Product Type:DC-DC Regulated Dual Output SMPS

Dimensions & Appearance

Height:0.40 in.
Width:0.80 in.
Length:1.25 in.

Operating conditions

Minimum Operating Temperature:-40°C
Maximum Operating Temperature:90°C

Input

Maximum Input Current:0.074 A
Input Voltage:48 VDC
Input Voltage Range:36 VDC to 72 VDC

Output

Number of Outputs:2
Output Current:0.10 A
Output Connector Type:DIP-24
Additional Output Voltages (VDC):-15 VDC
Output Voltage:15 VDC

Features

Pins:8
Efficiency:87%
Power Rating:3 W
,
