Dual Output 10W ±15V ±0.333A Isolated Regulated Encapsulated DC-DC Converter 48Vin
±15 Volts @ ±0.333 AmpsFeatures
- Input Voltage: 36 to 75 Volts DC
- DIP 1" x 1" package with industry standard pinout
- 2:1 wide input range
- Line regulation: ±0.2%
- Load regulation: ±1%
- Operating temperature range: -40°C to +85°C
- No minimum load required
- Complies to EN55032 radiated Class A without additional components
- High efficiency up to 89%
- Protections: Short circuit (continuous), overload, over voltage, input under voltage
- 1.5KV DC I/O isolation
- Remote ON/OFF control and Trimming output (±10%)
- 3 year warranty
Applications
- Telecom/Datacom systems
- Wireless network
- Industrial control facility
- Instrument
- Analyzer
- Detectors
- Data switch
Product Identification
Type:Isolated
Product Type:DC-DC Regulated Dual Output SMPS
Manufacturer Series:DKM10
Compliance
Agency Approvals:CE, FCC, EN, EAC, UKCA
Dimensions & Appearance
Color:Black
Height:0.40 in.
Width:1 in.
Length:1 in.
Operating conditions
Minimum Operating Temperature:-40°C
Maximum Operating Temperature:85°C
Input
Maximum Input Current:0.239 A
Input Voltage:48 VDC
Input Voltage Range:36 VDC to 75 VDC
Output
Number of Outputs:2
Additional Output Voltages (VDC):-15 VDC
Output Voltage:15 VDC
Output Current:0.333 A
Features
Pins:6
Efficiency:89%
Power Rating:10 W
