Dual Output 10W ±12V ±0.416A Isolated Regulated Encapsulated DC-DC Converter 5Vin

±12 Volts @ ±0.416 Amps

Features

  • Input Voltage: 4.7 to 9 Volts DC
  • DIP 1" x 1" package with industry standard pinout
  • 2:1 wide input range
  • Line regulation: ±0.2%
  • Load regulation: ±1%
  • Operating temperature range: -40°C to +85°C
  • No minimum load required
  • Complies to EN55032 radiated Class A without additional components
  • High efficiency up to 87%
  • Protections: Short circuit (continuous), overload, over voltage, input under voltage
  • 1.5KV DC I/O isolation
  • Remote ON/OFF control and Trimming output (±10%)
  • 3 year warranty

Applications

  • Telecom/Datacom systems
  • Wireless network
  • Industrial control facility
  • Instrument
  • Analyzer
  • Detectors
  • Data switch

Product Identification

Type:Isolated
Product Type:DC-DC Regulated Dual Output SMPS
Manufacturer Series:DKM10

Compliance

Agency Approvals:CE, FCC, EN, EAC, UKCA

Dimensions & Appearance

Color:Black
Height:0.40 in.
Width:1 in.
Length:1 in.

Operating conditions

Minimum Operating Temperature:-40°C
Maximum Operating Temperature:85°C

Input

Input Voltage:5 VDC
Input Voltage Range:4.7 VDC to 9 VDC
Maximum Input Current:2.295 A

Output

Number of Outputs:2
Additional Output Voltages (VDC):-12 VDC
Output Voltage:12 VDC
Output Current:0.416 A

Features

Pins:6
Efficiency:87%
Power Rating:10 W
,
