DC-DC Regulated Single Output Converter 8W 15V 106-533mA Output 36-72Vin PC Pins

Features

  • 2:1 wide input range
  • 1500V DC I/O isolation
  • Built-in EMI filter
  • Protections: short circuit, overload
  • Cooling by free air convection
  • Five-sided shield metal case
  • 100% full load burn-in test
  • Low cost, high reliability
  • 2-year warranty

Product Identification

Type:Regulated
Additional Feature:Built-in EMI Filter
Product Type:DC-DC Regulated Single Output Converter SMPS
Manufacturer Series:SCW08

Compliance

Agency Approvals:CE, FCC, EN, EAC, UKCA

Dimensions & Appearance

Color:Black
Height:0.48 in.
Width:0.80 in.
Length:1.25 in.

Operating conditions

Minimum Operating Temperature:-25°C
Maximum Operating Temperature:71°C

Input

Input Frequency:N/A
Maximum Input Current:0.215 A
Input Voltage:48 VDC
Input Voltage Range:36 VDC to 72 VDC

Output

Number of Outputs:1
Output Connector Diameters:N/A
Output Connector Type:PC Pins
Output Voltage:15 VDC
Output Current:0.533 A
Additional Output Voltages (VDC):N/A

Features

Isolation Voltage:1500V
Pins:8
AC Power Cord:N/A
Efficiency:81%
Power Rating:8 W
,
