DC-DC Regulated Single Output Converter 15W 15V 100-1000mA Output 36-72Vin PC Pins

Features

  • 2:1 wide input range
  • 1500V DC I/O isolation
  • Built-in EMI filter
  • Protections: short circuit, overload
  • Cooling by free air convection
  • Six-sided shield metal case
  • 100% full load burn-in test
  • Low cost, high reliability
  • Approvals: FCC, EAC, CE, UKCA
  • 2-year warranty

Product Identification

Type:Regulated
Product Type:DC to DC Converter and Switching Regulator Module SMPS
Additional Feature:Six-sided shield metal case
Manufacturer Series:SKE15

Compliance

Agency Approvals:CE, FCC, EN, EAC, UKCA

Dimensions & Appearance

Color:Black
Height:0.44 in.
Width:1 in.
Length:2 in.

Operating conditions

Minimum Operating Temperature:-25°C
Maximum Operating Temperature:71°C

Input

Input Frequency:N/A
Input Voltage:48 VDC
Input Voltage Range:36 VDC to 72 VDC
Maximum Input Current:0.4 A

Output

Number of Outputs:1
Output Connector Diameters:N/A
Output Connector Type:PC Pins
Output Voltage:15 VDC
Additional Output Voltages (VDC):N/A
Output Current:1 A

Features

Isolation Voltage:1500V
Pins:5
AC Power Cord:N/A
Efficiency:82%
Power Rating:15 W
,
