DC-DC Regulated Converter 1W 12V 8.3-83mA Output 36-72Vin 1500VDC Isolation SMD

Features

  • SMD package with industry standard pinout
  • 2:1 wide input range
  • Operating temperature range -40 to +90°C
  • 1500V DC I/O isolation
  • Complies with BS EN/EN55032 radiated Class A without additional components
  • Protections: Short circuit (continuous), overload
  • Optional reel packaging
  • 3-year warranty

Overview

SMT01 series is a 1W isolated and regulated module type DC-DC converter with SMD package. It features international standard pins, wide working temperature range -40 to +90C, 1500V I/P-O/P isolation voltage, compliance to BS EN/EN55032 radiated Class A without additional components, short circuit protection, etc. The models account for different input voltage 9-18V, 18-36V, and 36-72V 2:1 wide input range, and various output voltage, 5V/12V/15V for single output which are suitable for all kinds of systems such as industrial control, telecommunication field, distributed power architecture, and more.

Applications

  • Telecom/datacom system
  • Wireless network
  • Industrial control facility
  • Instrument
  • Analyzer
  • Detector
  • Data switch

Product Identification

Type:Regulated
Product Type:DC-DC Regulated Converter SMPS
Manufacturer Series:SMT01

Compliance

Agency Approvals:CE, EN, EAC, UKCA

Dimensions & Appearance

Color:Black
Height:0.28 in.
Length:0.60 in.
Width:0.43 In.

Operating conditions

Minimum Operating Temperature:-40°C
Maximum Operating Temperature:90°C

Input

Maximum Input Current:0.028 A
Input Frequency:N/A
Input Voltage:48 VDC
Input Voltage Range:36 VDC to 72 VDC

Output

Number of Outputs:1
Output Connector Diameters:N/A
Output Current:0.083 A
Output Voltage:12 VDC
Output Connector Type:SMD
Additional Output Voltages (VDC):N/A

Features

Isolation Voltage:1500V
Pins:10
AC Power Cord:N/A
Efficiency:75%
Power Rating:1 W
,
