151.2W DC/DC CONVERTER

Output: 24 Volts @ 6.3 Amps

Specifications:

  • Input Range: 36-72VDC
  • Size (L x W x H) (inches): 7.8 x 4.3 x 2.0
  • Number of pins: 7
  • Ripple and Noise (mV p-p): 150
  • Load Regulation: 0.3%
  • Line Regulation: 0.3%
  • Built-in EMI filter, low ripple noise
  • 2-year warranty
  • Certifications: CE

Product Identification

Type:Step Down
Product Type:DC to DC Power Supply SMPS
Manufacturer Series:SD-150

Compliance

Agency Approvals: EAC, EN, CE, CE, EN, EAC

Dimensions & Appearance

Mounting:Enclosed
Height:2 in.
Width:4.3 in.
Length:7.8 in.

Operating conditions

Minimum Operating Temperature:-10°C
Maximum Operating Temperature:60°C

Packaging

Package:Enclosed

Input

Input Voltage:48 VDC
Input Voltage Range:36 VDC to 72 VDC
Maximum Input Current:4.2 A

Output

Number of Outputs:1
Output Connector Type:Screw Terminal Block
Output Voltage:24 VDC
Additional Output Voltages (VDC):N/A
Output Current:6.30 A

Features

Switching Regulator:Yes
Pins:7
Efficiency:80%
Power Rating:151.2 W
,
