151.2W Single Output DC-DC Converter


Output: 24 Volts @ 6.3 Amps

Features:
  • Input voltage range: 19-36VDC
  • 2:1 wide input range
  • Built-in EMI filter
  • Protection: Short-circuit, overload, over-voltage
  • Low ripple noise
  • 100% full load burn-in test
  • 1500VDC I/O isolation
  • Efficiency: 77%
  • Size: 7.8"L x 4.3"W x 2.0"H
  • Weight: 1.9 lbs. (0.86 kg)
  • 2-year warranty

    • Product Identification

    Type:Step Down
    Product Type:DC to DC Power Supply SMPS
    Manufacturer Series:SD-150

    Compliance

    Agency Approvals: EAC, EN, CE, CE, EN, EAC

    Dimensions & Appearance

    Height:2 in.
    Width:4.3 in.
    Length:7.8 in.
    Mounting:Enclosed

    Operating conditions

    Minimum Operating Temperature:-10°C
    Maximum Operating Temperature:60°C

    Packaging

    Package:Enclosed

    Input

    Input Voltage:24 VDC
    Input Voltage Range:19 VDC to 36 VDC
    Maximum Input Current:8.5 A

    Output

    Number of Outputs:1
    Output Connector Type:Screw Terminal Block
    Output Voltage:24 VDC
    Additional Output Voltages (VDC):N/A
    Output Current:6.30 A

    Features

    Switching Regulator:Yes
    Pins:7
    Efficiency:77%
    Power Rating:151.2 W
    ,
