350.4W ENCLOSED DC/DC CONVERTER
24 Volts @ 14.6 Amps
Features:
- Input Voltage Range: 19V-36V
- 100% Full load burn-in test
- Protections: Short-circuit, Overload, Overvoltage, Overtemperature
- Number of terminal pins: 9
- Ripple & Noise: 150mVp-p
- Size: 8.5"L x 4.5"W x 2.0"H
- 2-year warranty
Product Identification
Type:Non-Inverting, Step Up, Step Down
Product Type:DC to DC Power Supply SMPS
Manufacturer Series:SD-350
Compliance
Agency Approvals: CE, EAC, EN, TUV, TUV, CE, EN, EAC
Dimensions & Appearance
Mounting:Enclosed
Height:2 in.
Width:4.5 in.
Length:8.5 in.
Operating conditions
Minimum Operating Temperature:-20°C
Maximum Operating Temperature:60°C
Packaging
Package:Enclosed
Input
Input Voltage:24 VDC
Input Voltage Range:19 VDC to 36 VDC
Maximum Input Current:17.6 A
Output
Number of Outputs:1
Output Connector Type:Screw Terminal Block
Output Voltage:24 VDC
Additional Output Voltages (VDC):N/A
Output Current:14.60 A
Features
Switching Regulator:No
Pins:9
Efficiency:80%
Power Rating:350.4 W
