25.2W Single Output DC-DC Converter


Output: 12 Volts @ 2.1 Amps

Features:
  • Input voltage range: 36-72VDC
  • Built-in EMI filter
  • Protection: Short-circuit, overload, over-voltage
  • Fixed switching frequency at 83kHz
  • 100% full load burn-in test
  • 1500VDC I/O isolation
  • Efficiency: 75%
  • Size: 3.9"L x 3.8"W x 1.4"H
  • Weight: 0.84 lbs. (380 grams)
  • 2-year warranty

    • Product Identification

    Type:Step Down
    Product Type:DC to DC Power Supply SMPS
    Manufacturer Series:SD-25

    Compliance

    Agency Approvals: EAC, EN, CE, CE, EN, EAC

    Dimensions & Appearance

    Mounting:Enclosed
    Height:1.4 in.
    Width:3.8 in.
    Length:3.9 in.

    Operating conditions

    Minimum Operating Temperature:-10°C
    Maximum Operating Temperature:60°C

    Packaging

    Package:Enclosed

    Input

    Input Voltage:48 VDC
    Input Voltage Range:36 VDC to 72 VDC
    Maximum Input Current:0.8 A

    Output

    Number of Outputs:1
    Output Voltage:12 VDC
    Output Connector Type:Screw Terminal Block
    Additional Output Voltages (VDC):N/A
    Output Current:2.10 A

    Features

    Pins:5
    Switching Regulator:Yes
    Efficiency:78%
    Power Rating:25.2 W
    ,
