DC-DC Medical Grade Regulated Converter 6W +/-15V +/-20-200mA 18-75Vin DIP-24

Features

  • DIP-24 package with international standard pinout
  • 4:1 wide input range
  • Operating temperature range: -40C to 90C
  • Medical safety approved (2xMOPP) according to IEC60601-1
  • Low patient leakage current <5µA
  • Protections: Short circuit (continuous), overload
  • 6KV DC or 4.2KV AC high I/O isolation (reinforced insulation)
  • 3-year warranty

Overview

The MDS06 and MDD06 series are 6W isolated and regulated module type medical grade DC-DC converter with DIP-24 package. It features international standard pins, a high efficiency up to 81%, wide working temperature range of -40C to +90C, 6KV DC or 4.2KV AC I/P-O/P high isolation voltage, compliance with IEC60601-1 medical standard, continuous-mode short circuit protection, and more. The models account for different input voltage 9-36V and 18-75V 4:1 wide input range, and various output voltage, 5V/12V/15V for single output and ±5V/±12V/±15V for dual outputs, which are suitable for medical systems, and ultra-low leakage current applications, and so on.

Applications

  • Medical devices
  • Medical oxygen monitor
  • CT scanning
  • Medical carts
  • Oral care equipment
  • Industrial control facility

Product Identification

Type:2xMOPP
Product Type:Medical Grade Regulated Converter SMPS
Manufacturer Series:MDD06

Compliance

Agency Approvals:CE, EN, EAC, UKCA

Dimensions & Appearance

Color:Black
Height:0.48 in.
Width:0.80 in.
Length:1.25 in.

Operating conditions

Minimum Operating Temperature:-40°C
Maximum Operating Temperature:90°C

Input

Input Frequency:N/A
Input Voltage:24 VDC, 48 VDC
Input Voltage Range:18 VDC to 75 VDC
Maximum Input Current:0.30 A

Output

Number of Outputs:2
Output Connector Diameters:N/A
Output Current:0.20 A, -0.20 A
Additional Output Voltages (VDC):-15 VDC
Output Connector Type:PC Pins
Output Voltage:15 VDC

Features

Pins:5
Isolation Voltage:6000V, 4200V
AC Power Cord:N/A
Efficiency:82%
Power Rating:6 W
,
