DC-DC Medical Grade Regulated Converter 3W +/-15V +/-10-100mA 9-36Vin DIP-24
Features
- DIP-24 package with international standard pinout
- 4:1 wide input range
- Operating temperature range: -40C to 90C
- Medical safety approved (2xMOPP) according to IEC60601-1
- Low patient leakage current <5µA
- Protections: Short circuit (continuous), overload
- 6KV DC or 4.2KV AC high I/O isolation (reinforced insulation)
- 3-year warranty
Overview
The MDS03 and MDD03 series are 3W isolated and regulated module type medical grade DC-DC converter with DIP-24 package. It features international standard pins, a high efficiency up to 81%, wide working temperature range of -40C to +90C, 6KV DC or 4.2KV AC I/P-O/P high isolation voltage, compliance with IEC60601-1 medical standard, continuous-mode short circuit protection, and more. The models account for different input voltage 9-36V and 18-75V 4:1 wide input range, and various output voltage, 5V/12V/15V for single output and ±5V/±12V/±15V for dual outputs, which are suitable for medical systems, and ultra-low leakage current applications, and so on.
Applications
- Medical devices
- Medical oxygen monitor
- CT scanning
- Medical carts
- Oral care equipment
- Industrial control facility
Product Identification
Type:2xMOPP
Manufacturer Series:MDD03
Product Type:Medical Grade Regulated Converter SMPS
Compliance
Agency Approvals:CE, EN, EAC, UKCA
Dimensions & Appearance
Color:Black
Height:0.48 in.
Width:0.80 in.
Length:1.25 in.
Operating conditions
Minimum Operating Temperature:-40°C
Maximum Operating Temperature:90°C
Input
Input Frequency:N/A
Input Voltage Range:9 VDC to 36 VDC
Input Voltage:12 VDC, 24 VDC
Maximum Input Current:0.32 A
Output
Number of Outputs:2
Output Connector Diameters:N/A
Output Current:0.10 A, -0.10 A
Additional Output Voltages (VDC):-15 VDC
Output Connector Type:PC Pins
Output Voltage:15 VDC
Features
Pins:5
Isolation Voltage:6000V, 4200V
AC Power Cord:N/A
Efficiency:79%
Power Rating:3 W
