DC-DC Medical Grade Regulated Converter 3W +/-12V +/-12.5-125mA 9-36Vin DIP-24

Features

• DIP-24 package with international standard pinout
• 4:1 wide input range
• Operating temperature range: -40C to 90C
• Medical safety approved (2xMOPP) according to IEC60601-1
• Low patient leakage current <5µA
• Protections: Short circuit (continuous), overload
• 6KV DC or 4.2KV AC high I/O isolation (reinforced insulation)
• 3-year warranty

Overview

The MDS03 and MDD03 series are 3W isolated and regulated module type medical grade DC-DC converter with DIP-24 package. It features international standard pins, a high efficiency up to 81%, wide working temperature range of -40C to +90C, 6KV DC or 4.2KV AC I/P-O/P high isolation voltage, compliance with IEC60601-1 medical standard, continuous-mode short circuit protection, and more. The models account for different input voltage 9-36V and 18-75V 4:1 wide input range, and various output voltage, 5V/12V/15V for single output and ±5V/±12V/±15V for dual outputs, which are suitable for medical systems, and ultra-low leakage current applications, and so on.

Applications

• Medical devices
• Medical oxygen monitor
• CT scanning
• Medical carts
• Oral care equipment
• Industrial control facility
