DC-DC Medical Grade Regulated Converter 15W 24V 625mA 9-18Vin 2xMOPP DIP

Features

  • DIP 2" x 1" package with international standard pinout
  • 2:1 wide input range
  • Operating temperature range: -40C to 90C
  • Medical safety approved (2xMOPP) according to IEC60601-1
  • Low patient leakage current <5µA
  • No minimum load required
  • Protections: Short circuit (continuous), overload, input under voltage
  • 4KV AC high I/O isolation (reinforced insulation)
  • 3-year warranty

Overview

The MDS15 series is a 15W isolated and regulated module type medical grade DC-DC converter with 2"x1" package. It features international standard pins, a high efficiency up to 88%, wide working temperature range of -40C to +90C, 4KV AC I/P-O/P high isolation voltage, compliance with IEC60601-1 medical standard, continuous-mode short circuit protection, and more. The models account for different input voltage 9-18V, 18-36V, and 36-75V 2:1 wide input range, and various output voltage, 5V/12V/15V/24V, which are suitable for medical systems, and ultra-low leakage current applications, and so on.

Applications

  • Medical devices
  • Medical oxygen monitor
  • CT scanning
  • Medical carts
  • Oral care equipment

Product Identification

Type:2xMOPP
Product Type:Medical Grade Regulated Converter SMPS
Manufacturer Series:MDS15

Compliance

Agency Approvals:CE, EN, EAC, UKCA

Dimensions & Appearance

Color:Black
Height:0.47 in.
Width:1 in.
Length:2 in.

Operating conditions

Minimum Operating Temperature:-40°C
Maximum Operating Temperature:90°C

Input

Input Frequency:N/A
Input Voltage Range:9 VDC to 18 VDC
Input Voltage:12 VDC
Maximum Input Current:1.45 A

Output

Number of Outputs:1
Output Connector Diameters:N/A
Output Connector Type:PC Pins
Output Voltage:24 VDC
Output Current:0.625 A
Additional Output Voltages (VDC):N/A

Features

Pins:4
Isolation Voltage:4000V
AC Power Cord:N/A
Efficiency:85%
Power Rating:15 W
,
