DC-DC Isolated Regulated Dual Output Converter 1W +/-12V +/-42mA 12Vin SIP-6
Features
- SIP6 package with industry standard pinout
- Operating temperature range -40 to +90°C
- Complies with BS EN/EN55032 radiated Class B without additional components
- Protections: Short circuit
- 1500V DC I/O isolation
- Low cost
- 3 year warranty
Applications
- Telecom/datacom system
- Wireless network
- Industrial control facility
- Instrument
- Analyzer
- Detector
- Data switch
Overview
SPRN01 and DPRN01 series are 1W isolated and regulated module type DC-DC converter in a SIP6 package. It features international standard pins, a wide working temperature range -40 to +90C, 1.5KV I/P-O/P isolation voltage, complies with BS EN/EN55032 radiated Class B without additional components, short circuit protection, and more. The models account for different input voltage 5V/12V/24V/48V (-5%/+10%), and various output voltage, 5V/12V/15V for single output and ±12V, ±15V for dual output which are suitable for all kinds of systems such as industrial control, telecommunication field, distributed power architecture, and more.
Product Identification
Type:Isolated
Product Type:DC-DC Regulated Dual Output SMPS
Manufacturer Series:DPRN01
Compliance
Agency Approvals:CE, EAC, UKCA
Dimensions & Appearance
Color:Black
Height:0.4 in.
Width:0.28 in.
Length:0.77 in.
Operating conditions
Minimum Operating Temperature:-40°C
Maximum Operating Temperature:90°C
Input
Input Frequency:N/A
Maximum Input Current:0.12 A
Input Voltage:12 VDC
Input Voltage Range:11.4 VDC to 13.2 VDC
Output
Number of Outputs:2
Output Current:0.042 A
Output Connector Diameters:N/A
Additional Output Voltages (VDC):-12 VDC
Output Voltage:12 VDC
Output Connector Type:PC Pins
Features
Pins:5
AC Power Cord:N/A
Efficiency:68%
Power Rating:1 W
