DC-DC Converter Isolated ±15VDC ±1000mA 2:1 Input 9-18VDCin 2x2" PC Mount

Features

  • 30W Isolated Output
  • 500 VDC Isolation
  • 2:1 Input Range
  • 2" x 2" Six-Sided Shield Metal Case
  • Regulated Outputs
  • Remote ON/OFF Control
  • CE Mark Meets 2004/108/EC
  • UL60950-1 Approval

Specifications

  • Output Voltage: ±15 VDC
  • Output Current: 0 mA to ±1000 mA
  • Input Voltage: 9 to 18 VDC (12 VDC nominal)
  • Input Current: 35 mA (no load); 3050 mA (full load)
  • Efficiency: 87%
  • Capacitor Load Max.: 1000 µF
  • Size: 2.00"W x 2.00"D x 0.40"H

Product Identification

Product Type:DC-DC Converter SMPS
Manufacturer Series:EC6

Dimensions & Appearance

Mounting:PCB

Packaging

Package:6-Sided Shield Metal Case

Input

Input Voltage Range:9 VDC to 18 VDC
Input Voltage:12 VDC

Output

Number of Outputs:2
Additional Output Voltages (VDC):-15
Output Voltage:15 VDC
Output Current:1 A

Features

Power Rating:30 W
,
