DC-DC Converter Isolated ±12VDC ±416mA 2:1 Input 18-36VDCin PCB Mount

Features

  • "T"= with Remote ON/OFF control (CMOS or open collector TTL, referenced to ground)
  • 10W Isolated Output
  • 1500 VDC Isolation
  • 2:1 Input Range
  • Regulated Outputs
  • Fixed Switching Frequency
  • Input Under Voltage Protection
  • Over Current Protection
  • Conductive EMI Meets EN55022 Class A
  • Continuous Short Circuit Protection
  • Without Tantalum Capacitor Inside
  • CE Mark Meets 2004/108/EC
  • Safety Meets UL60950-1, EN60950-1 and IEC60950-1

Specifications

  • Output Voltage: ±12 VDC
  • Output Current: 0 mA to ±416 mA
  • Input Voltage: 18 to 36 VDC (24 VDC nominal)
  • Input Current: 25 mA (no load); 478 mA (full load)
  • Efficiency: 87%
  • Capacitor Load Max.: 440 µF
  • Size: 2.00"W x 1.00"D x 0.40"H

Product Identification

Product Type:DC-DC Converter SMPS
Manufacturer Series:EC4BU

Compliance

Agency Approvals:UL, CE, EN

Dimensions & Appearance

Mounting:PCB

Packaging

Package:Enclosed Module

Input

Input Voltage:24 VDC
Input Voltage Range:18 VDC to 36 VDC
Maximum Input Current:0.478 A

Output

Number of Outputs:2
Additional Output Voltages (VDC):-12
Output Voltage:12 VDC
Output Connector Type:PC Pins
Output Current:0.416 A

Features

Power Rating:10 W
,
