DC-DC Converter Isolated 5VDC 3000mA 4:1 Input 9-36VDCin DIP-24

Features

  • 15W Isolated Output
  • 1500 VDC Isolation
  • DIP-24 Metal Package
  • Low No Load Power Consumption
  • 4:1 Input Range
  • Regulated Outputs
  • Conductive EMI Meet EN55022 Class A without External Components
  • Continuous Short Circuit Protection
  • No Tantalum Capacitor Inside
  • CE Mark Meets 2004/108/EC
  • Safety Meets UL60950-1, EN60950-1 and IEC60950-1

Specifications

  • Output Voltage: 5 VDC
  • Output Current: 0 mA to 3000 mA
  • Input Voltage: 9 to 36 VDC (24 VDC nominal)
  • Input Current: 8 mA (no load); 694 mA (full load)
  • Efficiency: 90%
  • Capacitor Load Max.: 3000 µF
  • Size: 1.25"W x 0.80"D x 0.40"H

Product Identification

Product Type:DC-DC Converter SMPS
Manufacturer Series:EC8AW

Compliance

Agency Approvals:UL, CE

Dimensions & Appearance

Height:0.40 in.
Width:0.80 in.
Length:1.25 in.
Mounting:PCB

Operating conditions

Minimum Operating Temperature:-40°C
Maximum Operating Temperature:85°C

Packaging

Package:DIP-24

Input

Input Voltage Range:9 VDC to 36 VDC
Input Voltage:24 VDC
Maximum Input Current:0.694 A

Output

Number of Outputs:1
Output Connector Type:DIP-24 (0.6"W)
Output Voltage:5 VDC
Additional Output Voltages (VDC):N/A
Output Current:3 A

Features

Pins:8
AC Power Cord:N/A
Efficiency:90%
Power Rating:15 W
,
