DC-DC Converter Isolated 5VDC 20A 4:1 Input 18-75VDCin Quarter-Brick Board Mount

Features

  • 100W Isolated Output
  • 4:1 Input Range
  • Regulated Outputs
  • Input Under Voltage Protection
  • Over Temperature Protection
  • Over Voltage/Current Protection
  • Remote ON/OFF
  • 1500 VDC Isolation
  • Quarter-Brick Package
  • Safety Meets UL60950-1

Specifications

  • Output Voltage: 5 VDC
  • Output Current: 0 mA to 20 A
  • Input Voltage: 18 to 75 VDC (48 VDC nominal)
  • Input Current: 60 mA (no load); 2.367 A (full load)
  • Efficiency: 88%
  • Capacitive Load: 10,000 µF (max.)
  • Size: 1.45"W x 2.28"D x 0.5"H

Product Identification

Product Type:DC-DC Converter SMPS
Manufacturer Series:CQB100W

Compliance

Agency Approvals:UL

Dimensions & Appearance

Mounting:PCB
Height:0.5 in.
Width:1.45 in.
Length:2.28 in.

Operating conditions

Maximum Operating Temperature:100°C
Minimum Operating Temperature:-40°C

Packaging

Package:Quarter Brick

Input

Input Voltage Range:18 VDC to 75 VDC
Input Voltage:48 VDC
Maximum Input Current:2.367 A

Output

Number of Outputs:1
Output Voltage:5 VDC
Output Connector Type:PC Pins
Additional Output Voltages (VDC):N/A
Output Current:20 A

Features

Pins:8
Efficiency:88%
Power Rating:100 W
,
