DC-DC Converter Isolated 5VDC 1200mA 4:1 Input 18-75VDCin SIP-8

Features

  • 6W Isolated Output
  • 1500 VDC Isolation
  • 4:1 Input Range
  • Regulated Outputs
  • Remote ON/OFF Control
  • Continuous Short Circuit Protection
  • Non-Conductive Black Plastic

Specifications

  • Output Voltage: 5 VDC
  • Output Current: 0 mA to 1200 mA
  • Input Voltage: 18 to 75 VDC (48 VDC nominal)
  • Input Current: 3 mA (no load); 150 mA (full load)
  • Efficiency: 85%
  • Capacitor Load Max.: 2200 µF
  • Size: 0.86"W x 0.36"D x 0.44"H

Product Identification

Manufacturer Series:EC4SAW
Product Type:DC-DC Converter SMPS

Compliance

Agency Approvals:CE

Dimensions & Appearance

Mounting:PCB
Height:0.44 in.
Width:0.36 in.
Length:0.86 in.

Operating conditions

Minimum Operating Temperature:-40°C
Maximum Operating Temperature:85°C

Packaging

Package:SIP-8

Input

Maximum Input Current:0.15 A
Input Voltage Range:18 VDC to 75 VDC
Input Voltage:48 VDC

Output

Number of Outputs:1
Output Connector Type:SIP-8
Output Voltage:5 VDC
Additional Output Voltages (VDC):N/A
Output Current:1.20 A

Features

Pins:7
Efficiency:85%
Power Rating:6 W
,
