DC-DC Converter Isolated 24VDC 6.3A 2:1 Input 180-425VDCin Quarter-Brick Board Mount

Features

  • 150W Isolated Output
  • 2:1 Input Range
  • Fixed Switching Frequency
  • Regulated Outputs
  • Low No Load Power Consumption
  • Input Under Voltage Protection
  • Over Temperature Protection
  • Over Voltage/Current Protection
  • Continuous Short Circuit Protection
  • Remote ON/OFF
  • 1500 VDC Isolation
  • Quarter-Brick Package Meets Industrial Standard
  • UL60950-1 2nd (Reinforced Insulation) Approval
  • CB Test Certificate IEC60950-1
  • Shock & Vibration Meets EN50155 (EN61373)
  • Fire & Smoke Meets EN45545-2

Specifications

  • Output Voltage: 24 VDC
  • Output Current: 0 mA to 6.3 A
  • Input Voltage: 180 to 425 VDC (300 VDC nominal)
  • Input Current: 10 mA (no load); 0.57 A (full load)
  • Efficiency: 88.5%
  • Capacitive Load: 3300 µF (max.)
  • Size: 2.28"W x 1.45"D x 0.5"H

Product Identification

Product Type:DC-DC Converter SMPS
Manufacturer Series:CQB150

Compliance

Agency Approvals:UL, CUL, CB, CE, EN

Dimensions & Appearance

Height:0.5 in.
Width:1.45 in.
Length:2.28 in.
Mounting:PCB

Operating conditions

Maximum Operating Temperature:105°C
Minimum Operating Temperature:-40°C

Packaging

Package:Quarter Brick

Input

Input Voltage Range:180 VDC to 425 VDC
Maximum Input Current:0.57 A
Input Voltage:300 VDC

Output

Number of Outputs:1
Output Connector Type:PC Pins
Output Voltage:24 VDC
Additional Output Voltages (VDC):N/A
Output Current:6.30 A

Features

Pins:8
Efficiency:88.5%
Power Rating:151.2 W
,
