DC-DC Converter Isolated 24VDC 31.2A 2:1 Input 200-425VDCin Full Brick Board Mount

Features

  • 748.8W Isolated Output
  • Fixed Switching Frequency
  • Input Under Voltage Protection
  • Over Temperature Protection
  • Over Voltage/Current Protection
  • Remote On/Off
  • Single Wire Parallel
  • Full-Brick Size Meet Industry Standard
  • Fully Isolated 3000VDC
  • CE, UL60950-1 Approval

Specifications

  • Output Voltage: 24 VDC
  • Output Current: 0 mA to 31.2 A
  • Input Voltage: 200 to 425 VDC
  • Input Current: 10 mA (no load); 2.78 A (full load)
  • Efficiency: 90%
  • Capacitive Load: 10,000 µF (max.)

Product Identification

Manufacturer Series:CFB750
Product Type:DC-DC Converter SMPS

Compliance

Agency Approvals:UL, CE

Dimensions & Appearance

Mounting:PCB
Height:0.5 in.
Width:2.4 in.
Length:4.6 in.

Operating conditions

Minimum Operating Temperature:-40°C
Maximum Operating Temperature:85°C

Packaging

Package:Full Brick

Input

Input Voltage Range:200 VDC to 425 VDC
Input Voltage:300 VDC
Maximum Input Current:2.78 A

Output

Number of Outputs:1
Output Connector Type:PC Pins
Output Voltage:24 VDC
Additional Output Voltages (VDC):N/A
Output Current:31.20 A

Features

Pins:16
Efficiency:90%
Power Rating:748.8 W
,
