DC-DC Converter Isolated 24VDC 2.5A 4:1 Input 43-160VDCin Quarter-Brick Board Mount

Features

  • Railway system
  • 60W Isolated Output
  • 4:1 Input Range
  • Regulated Outputs
  • Low No Load Power Consumption
  • Over Temperature Protection
  • Over Voltage/Current Protection
  • Continuous Short Circuit Protection
  • Remote ON/OFF
  • Quarter-Brick Package Meets Industrial Standard
  • UL60950-1 (Basic) Approval
  • Meets EN50155 with External Circuits
  • Shock & Vibration Meets EN50155 (EN61373)
  • CE Mark Meets 2014/30/EU
  • Fire & Smoke Meets EN45545-2 Compliant
  • 4000m Operating Altitude

Specifications

  • Output Voltage: 24 VDC
  • Output Current: 0 mA to 2.5 A
  • Input Voltage: 43 to 160 VDC (110 VDC nominal)
  • Input Current: 5 mA (no load); 606 mA (full load)
  • Efficiency: 90%
  • Capacitive Load: 1200 µF (max.)
  • Size: 2.28"W x 1.45"D x 0.5"H

Product Identification

Manufacturer Series:CQB60W
Product Type:DC-DC Converter SMPS

Compliance

Agency Approvals:UL, CUL, CE, EN

Dimensions & Appearance

Mounting:PCB
Height:0.5 in.
Width:1.45 in.
Length:2.28 in.

Operating conditions

Maximum Operating Temperature:100°C
Minimum Operating Temperature:-40°C

Packaging

Package:Quarter Brick

Input

Input Voltage Range:43 VDC to 160 VDC
Input Voltage:110 VDC
Maximum Input Current:0.606 A

Output

Number of Outputs:1
Output Connector Type:PC Pins
Output Voltage:24 VDC
Additional Output Voltages (VDC):N/A
Output Current:2.50 A

Features

Pins:8
Efficiency:90%
Power Rating:60 W
,
