DC-DC Converter Isolated 15VDC 200mA 2:1 Input 18-36VDCin DIP-24

Features

  • 3W Isolated Output
  • 3000 VDC Isolation Voltage (non-conductive black plastic only)
  • DIP-24 Package
  • 2:1 Input Range
  • Regulated Outputs
  • Pi-type Input Filter
  • Continuous Short Circuit Protection
  • No Tantalum Capacitor Inside
  • Meet EMI EN55022 Class A
  • Wide Operating Temperature Range
  • UL60950-1 2nd Approval

Specifications

  • Output Voltage: 15 VDC
  • Output Current: 0 mA to 200 mA
  • Input Voltage: 18 to 36 VDC (24 VDC nominal)
  • Input Current: 7.5 mA (no load); 145 mA (full load)
  • Efficiency: 86%
  • Capacitive Load: 2200 µF (max.)
  • Size: 1.25"W x 0.80"D x 0.40"H

Product Identification

Manufacturer Series:EC3A
Product Type:DC-DC Converter SMPS

Compliance

Agency Approvals:UL, CUL, CE

Dimensions & Appearance

Mounting:PCB
Height:0.40 in.
Width:0.80 in.
Length:1.25 in.

Operating conditions

Minimum Operating Temperature:-40°C
Maximum Operating Temperature:85°C

Packaging

Package:DIP-24

Input

Maximum Input Current:0.145 A
Input Voltage:24 VDC
Input Voltage Range:18 VDC to 36 VDC

Output

Number of Outputs:1
Output Connector Type:DIP-24 (0.6"W)
Output Current:0.20 A
Output Voltage:15 VDC
Additional Output Voltages (VDC):N/A

Features

Pins:10
Efficiency:86%
Power Rating:3 W
,
