DC-DC Converter Isolated 12VDC 666mA 4:1 Input 9-36VDCin DIP-24

Features

  • 8W Isolated Output
  • 1500 VDC Isolation
  • 4:1 Input Range
  • Regulated Outputs
  • Remote ON/OFF Control
  • Input Under-Voltage Protection
  • Continuous Short Circuit Protection
  • Without Tantalum Capacitors Inside
  • Safety Meets UL60950-1, EN60950-1 and IEC60950-1
  • Meets EN50155 with External Circuits
  • Shock & Vibration Meets EN50155 (EN61373)
  • DIP-24 Metal Package

Specifications

  • Output Voltage: 12 VDC
  • Output Current: 0 mA to 666 mA
  • Input Voltage: 9 to 36 VDC (24 VDC nominal)
  • Input Current: 10 mA (no load); 392 mA (full load)
  • Efficiency: 85%
  • Capacitor Load Max.: 666 µF
  • Size: 1.25"W x 0.80"D x 0.40"H

Product Identification

Manufacturer Series:EC6AW
Product Type:DC-DC Converter SMPS

Dimensions & Appearance

Mounting:PCB

Packaging

Package:DIP-24

Input

Input Voltage Range:9 VDC to 36 VDC
Input Voltage:24 VDC

Output

Number of Outputs:1
Output Voltage:12 VDC
Additional Output Voltages (VDC):N/A
Output Current:0.666 A

Features

Power Rating:8 W
,
