DC-DC Converter Isolated 12VDC 500mA 4:1 Input 9-36VDCin SIP-8

Features

  • 6W Isolated Output
  • 1500 VDC Isolation
  • 4:1 Input Range
  • Regulated Outputs
  • Remote ON/OFF Control
  • Continuous Short Circuit Protection
  • Non-Conductive Black Plastic

Specifications

  • Output Voltage: 12 VDC
  • Output Current: 0 mA to 500 mA
  • Input Voltage: 9 to 36 VDC (24 VDC nominal)
  • Input Current: 5 mA (no load); 288 mA (full load)
  • Efficiency: 88%
  • Capacitor Load Max.: 1100 µF
  • Size: 0.86"W x 0.36"D x 0.44"H

Product Identification

Product Type:DC-DC Converter SMPS
Manufacturer Series:EC4SAW

Dimensions & Appearance

Mounting:PCB

Packaging

Package:SIP-8

Input

Input Voltage Range:9 VDC to 36 VDC
Input Voltage:24 VDC

Output

Number of Outputs:1
Output Voltage:12 VDC
Output Current:0.50 A
Additional Output Voltages (VDC):N/A

Features

Power Rating:6 W
,
