40W Regulated Single Output DC-DC Converter

Output: 15 Volts @ 2.67 Amps

Features:

  • Input voltage range: 9-18VDC
  • Built-in EMI filter
  • Built-in remote sense and remote on/off control
  • Trimming output ±10%
  • Cooling by free air convection
  • Protection: Short-circuit, overload, over-voltage
  • 100% burn-in test
  • 1500VDC I/O isolation
  • Six-sided shielded metal case
  • Efficiency: 90%
  • Compact size: 2.0"L x 2.0"W x 0.43"H
  • Weight: 2.11 oz. (60 grams)
  • 2-year warranty

Product Identification

Type:Non-Inverting, Step Up, Step Down
Product Type:DC-DC Regulated Single Output Converter SMPS
Manufacturer Series:SKA40

Dimensions & Appearance

Height:0.43 in.
Width:2 in.
Length:2 in.

Operating conditions

Minimum Operating Temperature:-40°C
Maximum Operating Temperature:80°C

Input

Input Voltage Range:9 VDC to 18 VDC
Input Voltage:12 VDC

Output

Number of Outputs:1
Output Voltage:15 VDC
Additional Output Voltages (VDC):N/A
Output Current:2.67 A

Features

Pins:8
Power Rating:40 W
,
