Connector Power HDR 3 Position 4.2mm Solder Right Angle Through Hole 3 Terminal

Specifications

  • Number of Positions: 3
  • Pitch: 4.2mm
  • Number of Rows: 1
  • Mounting Style: Board Lock
  • Termination Style: Through Hole
  • Mounting Angle: Right Angle
  • Contact Gender: Pin (Male)
  • Tin Contact Plating
  • Contact Material: Brass
  • Current Rating: 13A
  • Housing Material: Nylon
  • Voltage Rating: 600V
  • Wire Gauge: 20-16

    • Product Identification

    Additional Feature:N/A
    Manufacturer Series:Mini-Fit Jr 5569
    Product Type:Header

    Dimensions & Appearance

    Body Orientation:Right Angle
    Mounting:Through Hole
    Body/Shell Style:Board to Cable/Wire Shrouded - 4 Wall

    Features

    Number of Rows:1
    Filter Feature:No
    Contact Material:Brass
    Number of Contacts:4
    Housing Color:Natural
    UL Flammability Code:UL 94 V-2
    Maximum Contact Resistance:N/A
    Fastening Method:Locking Ramp
    Housing Material:Nylon
    Contact Plating:Tin
    Gender:Male Pin
    Termination:Solder
    Voltage Rating:600 V
    Current Rating:13 A
    ,
