Connector D-Subminiature PIN 9 Position 2.74 mm Solder Straight Thru-Hole 9 Terminal 1 Port

Product Identification

Manufacturer Series:5745410
Product Type:D-Subminiature

Dimensions & Appearance

Body Orientation:Straight
Mounting:Through Hole
Depth:12.54 mm
Height:17.5 mm
Length:30.81 mm
Body Plating:Tin Over Copper

Features

Number of Rows:2
Contact Material:Brass
Number of Contacts:9
Housing Material:Carbon Steel
Contact Plating:Gold Over Nickel
Pitch:2.74 mm
Gender:PL
Termination:Solder
,
