Compact Power Supply DIN Rail 85-264VAC Input 48VDC Output 120W 2.5A Compact PFC
Features
- Universal AC input range(85 to 264Vac)
- Support 1+1 or N+1 redundant system (suggest to use redundancy modules.)
- Built-in active PFC, PF>0.95
- High efficiency up to 92%
- Built-in current sharing function
- Built-in current limiting circuit
- Output protections: OVP/OLP/SCP/OTP
- Wide operating ambient temp (-25°Cto70°C)
- 150% (180W) peak load capacity
- Easy Fuse Tripping due to High Overload Current
- Excellent Partial Load Efficiency
- Built-in DC OK relay contact
- Can be installed on 35 mm DIN rail
- 100% full load burn-in test
- PCB with conformal coating
- Suitable for critical applications
- Ultra-slim, 32mm width
- 3 years warranty
Overview
Compact Power Supply DIN Rail 85-264VAC Input 48VDC Output 120W 2.5A Compact PFC
Product Identification
Product Type:Ultra-Compact Single Phase DIN Rail Power Supply
Manufacturer Series:PSC-120
Compliance
Agency Approvals: CE, CUL, EAC, EN, UKCA, UL
Dimensions & Appearance
Color:Silver
Depth:4.69 in.
Width:1.26 in.
Height:4.88 in.
Operating conditions
Minimum Operating Temperature:-25°C
Maximum Operating Temperature:70°C
Input
Input Frequency:47 Hz to 63 Hz
Input Voltage:85 VAC to 264 VAC
Maximum Input Current:1.3 A
Output
Number of Outputs:1
Output Connector Type:Screw Terminal Block
Output Voltage:48 VDC
Additional Output Voltages (VDC):48 to 56
Output Current:2.50 A
Features
Low Power Source (LPS):No
PFC Function:Yes
Minimum Isolation Voltage:3000V
Efficiency:92%
Power Rating:120 W
